Parameter sets of signal modules
A.2 Parameters of digital IO modules
S7-300 Module data
524 Manual, 06/2017, A5E00105505-AJ
A.2 Parameters of digital IO modules
Parameter
The table below lists the parameters you can set for digital input modules.
Note
For details on parameters of programmable digital IO modules, see the chapter dealing with
the relevant module.
The comparison illustrates the parameters you can edit:
● in
STEP 7
● using SFC55 "WR_PARM"
● using SFB53 "WRREC" (for GSD, for example).
Parameters set in
STEP 7 may also be transferred to the module using SFCs 56 and 57, and
SFB53 (refer to the
STEP 7 ) Online Help).
Table A- 2 Parameters of digital IO modules
Parameters
Data record num-
ber
Programmable, using ...
... SFC55,
SFB53
... PG
Input delay
0
no
yes
Diagnostics of missing encoder supply
no
yes
Wire-break diagnostics
no
yes
Hardware interrupt enable
1
yes
yes
Diagnostics interrupt enable
yes
yes
Hardware interrupt at positive edge
yes
yes
Hardware interrupt at negative edge
yes
yes
Note
To enable diagnostics interrupts in the user program at data record 1, you first need to
enable diagnostics at data record 0 in
STEP 7 .
