Digital modules
3.35 Relay output module SM 322; DO 8 x Rel. 230VAC/5A; (6ES7322-5HF00-0AB0)
S7-300 Module data
214 Manual, 06/2017, A5E00105505-AJ
3.35.1 Parameters of SM 322; DO 8 x Rel. AC 230V/5A
Parameters of SM 322; DO 8 x Rel. AC 230V/5A
The table below provides an overview of configurable parameters and defaults for SM 322;
DO 8 x Rel. AC 230V/5A.
The defaults apply if you have not set any parameters in STEP 7.
Table 3- 35 Parameters of SM 322; DO 8 x Rel. AC 230V/5A
Parameters
Range of values
Defaults
Parameter type
Scope
Enable
• Diagnostic interrupts
yes/no no Dynamic Module
Reaction to CPU STOP Set substitution value (SSV)
Hold last value (HLV)
SSV Dynamic Channel
Set substitution value "1"
yes/no
no
Dynamic
Channel
See also
Programming digital modules (Page 58)
3.35.2 SM 322; DO 8 x Rel. AC 230V/5A - Diagnostics
Diagnostics messages of SM 322; DO 8 x Rel. AC 230V/5A
The table below provides an overview of the diagnostic messages of
SM 322; DO 8 x Rel. AC 230V/5A.
Table 3- 36 Diagnostics messages of SM 322; DO 8 x Rel. AC 230V/5A
Diagnostics message
LED
Scope of diagnostics
programmable
Watchdog time-out
SF
Module
no
EPROM error
SF
Module
no
RAM error
SF
Module
no
