Siemens SIMATIC User Manual

Analog modules
6.15 Analog output module SM 332; AO 2 x 12 Bit; (6ES7332-5HB01-0AB0)
S7-300 Module data
468 Manual, 06/2017, A5E00105505-AJ
6.15 Analog output module SM 332; AO 2 x 12 Bit;
(6ES7332-5HB01-0AB0)
Order number: "Standard module"
6ES7332-5HB01-0AB0
Order number: "SIPLUS S7-300 module"
6AG1332-5HB01-2AB0
Properties
● 2 outputs in one group
● The outputs can be set separately as
– voltage output
– current output
● Resolution 12 bits
● Programmable diagnostics and diagnostic interrupt
● Electrically isolated to backplane bus interface and load voltage
● Supports parameter reassignment in RUN
Diagnostics
For information on diagnostic messages at the "group diagnostics" parameter, refer to
chapter Diagnostic messages of analog output modules (Page 296).
Terminal assignment
The diagrams below show various wiring options.
Note
When you switch the rated load voltage (L+) off and on, the outputs can return incorrect
voltag
e/current values for the duration of about 500 ms.
