Analog modules
6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)
S7-300 Module data
450 Manual, 06/2017, A5E00105505-AJ
6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone;
(6ES7332-7ND02-0AB0)
Order number
6ES7332-7ND02-0AB0
Order number: "SIPLUS S7-300 module"
6AG1332-7ND02-4AB0
Properties
● 4 outputs in 4 channel groups
● The output channels can be programmed as
– Voltage output
– Current output
● Resolution 16 bits
● Supports isochronous mode
● Supports parameter reassignment in RUN
● Programmable diagnostics and diagnostic interrupt
● Electrical isolation between:
– backplane bus interface and analog output channel
– analog output channels
– analog output and L+, M
– Backplane bus circuit and L+, M
● Supports parameter reassignment in RUN
Diagnostics
For information on diagnostic messages at the "group diagnostics" parameter, refer to
chapter Diagnostic messages of analog output modules (Page 296).
Terminal assignment
The diagrams below show various wiring options.
Note
When you switch the rated load voltage (L+) off and on, the output may carry invalid interim
values for the duration of ca. 10 ms.
