Interface modules

This chapter described the technical data and properties of the S7-300 interface modules.

8.1 Module overview

Introduction

The table below summarizes the essential features of the interface modules described in this

chapter. This overview supports you in selecting a module to suit your requirements.

Table 8- 1 Interface modules: Overview of properties

Properties

Interface module IM 360

Interface module IM 361

Interface module IM 365

Suitable for installation

in S7-300 racks

• 0 • 1 to 3 • 0 and 1

Data transfer

• from IM 360 to

IM 361 via connect-

ing cable 386

• from IM 360 to

IM 361, or from IM

361 to IM 361, via

connecting cable 386

• from IM 365 to IM 365 via connecting

cable 386

Distance between...

• max. 10 m • max. 10 m • 1 m, permanently connected

Special features --- ---

• Preassembled module pair

• Rack 1 supports only signal modules

• IM 365 does not route the communica-

tion bus to rack 1
