Digital modules

3.37 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A; (6ES7323-1BL00-0AA0)

S7-300 Module data

222 Manual, 06/2017, A5E00105505-AJ

3.37 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A;

(6ES7323-1BL00-0AA0)

Order number

6ES7323-1BL00-0AA0

Properties

Properties of SM 323; DI 16/DO 16 x DC 24 V/0.5 A:

● 16 inputs, electrically isolated in groups of 16

● 16 outputs, electrically isolated in groups of 8

● Rated input voltage 24 V DC

● Rated load voltage 24 V DC

● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)

● Outputs capable of driving solenoid valves, DC contactors and indicator lights

Use of the module with high-speed counters

Please note when using the module in combination with high-speed counters:

Note

When using a mechanical contact to switch on the 24

-V power supply to SM 323; DI 16/DO

x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca. 50 µs, due to the

circuit structure.
