8.2 Interface module IM 360; (6ES7360-3AA01-0AA0)
S7-300 Module data
516 Manual, 06/2017, A5E00105505-AJ
8.2 Interface module IM 360; (6ES7360-3AA01-0AA0)
Order number
6ES7360-3AA01-0AA0
Properties
Special features of interface module IM 360:
● Interface for rack 0 of the S7-300
● Data transfer from IM 360 to IM 361 via connecting cable 368
● Maximum distance between IM 360 and IM 361 is 10 m
Status and error LEDs
Interface module IM 360 is equipped with the following status and error LEDs.
Display element
Meaning
Explanations
SF Group error The LED lights up if
• the connecting cable is missing.
• IM 361 is switched off.
Front view
The figure below shows the front view of interface module IM 360
