Siemens SIMATIC User Manual

Analog modules
6.16 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit; (6ES7334-0CE01-0AA0)
S7-300 Module data
476 Manual, 06/2017, A5E00105505-AJ
6.16 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit;
(6ES7334-0CE01-0AA0)
Order number
6ES7334-0CE01-0AA0
Properties
● 4 inputs in one group and 2 outputs in one group
● Resolution 8 bits
● Programmable measurement type at each channel group
– Voltage
– Current
● Not programmable, measurement and output type defined by hardwiring
● Connected to potential of the backplane bus interface
● Electrically isolated to load voltage
Terminal assignment
The diagrams below show various wiring options.
Note
Note when wiring the SM 334:
•
analog ground
M
ANA
(terminal 15 or 18) is interconnected with chassis ground M of the
CPU or interface module IM.
Use a cable with a conductor cross-section of at least
1 mm
2
.
The module will shut down if the ground connection between M
ANA
and M is missing.
Inputs are read with 7FFF
H
, and outputs return a value of 0. The module may be
destroyed if operated without ground over a longer period of time.
•
the
supply voltage for the CPU and/or the interface module (IM) may not be connected
with reversed polarity
. Reverse polarity will inevitably lead to the destruction of the
module, because M
ANA
develops an impermissible high potential (+24 V.)
