Digital modules
3.36 Relay output module SM 322; DO 8 x Rel. AC 230 V/5 A; (6ES7322-1HF10-0AA0)
S7-300 Module data
216 Manual, 06/2017, A5E00105505-AJ
3.36 Relay output module SM 322; DO 8 x Rel. AC 230 V/5 A;
(6ES7322-1HF10-0AA0)
Order number: "Standard module"
6ES7322-1HF10-0AA0
Order number: "SIPLUS S7-300 module"
6AG1322-1HF10-2AA0
Properties
The SM 322; DO 8 x Rel. 230 V AC / 5 A is characterized by the following properties:
● 8 outputs, electrically isolated in groups of 1
● Rated load voltage 24 to 120 V DC, 48 V to 230 V AC
● Suitable for AC/DC solenoid valves, contactors, motor starters, FHP motors and signal
lamps.
Measures to take for switching currents > 3 A
use connecting cables with a cross-section of 1.5 mm
2
when operating with switching
currents > 3 A in order to reduce any temperature rise in the connector area of the module to
a minimum.
