Digital modules
3.24 Digital output module SM 322; DO 16 x DC 24 V/0.5 A: (6ES7322-8BH10-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
147
3.24 Digital output module SM 322; DO 16 x DC 24 V/0.5 A:
(6ES7322-8BH10-0AB0)
Order number
6ES7322-8BH10-0AB0
Order number: "SIPLUS S7-300 module"
6AG1322-8BH10-7AB0
Properties
The digital output module SM 322; DO 16 x DC24 V/0.5 A is distinguished by the following
properties:
● 16 outputs, electrically isolated in groups of 4 channels
● A nominal load voltage of 24 V DC
● Configurable diagnostics
● Programmable diagnostic interrupt
● Redundant
● Wire break at "0" and "1" signal
● Identification Data
● Firmware update possible
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters.
Note
When using a mechanical contact to switch on the 24
-V power supply to SM 322; DO
16
x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca. 50 µs, due to the
circuit structure.
