Interface modules
8.3 Interface module IM 361; (6ES7361-3CA01-0AA0)
S7-300 Module data
518 Manual, 06/2017, A5E00105505-AJ
8.3 Interface module IM 361; (6ES7361-3CA01-0AA0)
Order number
6ES7361-3CA01-0AA0
Properties
Special features of interface module IM 361:
● 24 VDC power supply
● Interface for racks 1 to 3 of the S7-300
● Current output via the S7-300 backplane bus: max. 0.8 A
● Data transfer from IM 360 to IM 361, or from IM 361 to IM 361 via connecting cable 368
● Maximum distance between IM 360 and IM 361 is 10 m
● Maximum distance between IM 361 and IM 361 is 10 m
Status and error LEDs
Interface module IM 361 is equipped with the following status and error LEDs.
Display element
Meaning
Explanations
SF Group error The LED lights up if
• the connecting cable is missing
• the IM 361 connected in series is switched off
• the CPU is in POWER OFF state
5 VDC 5 VDC supply for the S7-300 backplane bus -
