Siemens SIMATIC User Manual

Analog modules
6.6 Analog input module SM 331; AI 8 x 13 Bit; (6ES7331-1KF02-0AB0)
S7-300 Module data
348 Manual, 06/2017, A5E00105505-AJ
6.6.1 Measurement types and measuring ranges
Introduction
The measurement type and range is configured at the "measuring type" parameter in
STEP 7 .
Selected type of measurement
Measuring range
Voltage
V:
± 50 mV
± 500 mV
± 1 V
± 5 V
1 V to 5 V
0 V to 10 V
± 10 V
Current I 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
resistance (4-wire connection)
R-4L
6 kΩ
600 Ω
PTC
Thermal resistance
RTD-4L (linear, 4-wire connection)
(temperature measurement)
Silicon temperature sensors
Pt 100 Klima / Standard
Ni 100 Klima / Standard
Ni 1000 Klima / Standard
LG-Ni 1000 Klima / Standard
KTY83/110
KTY84/130
6.6.2 Programmable parameters
Introduction
You will find a description of the general procedure for assigning parameters to analog
modules in section Programming analog modules (Page 294).
