Siemens SIMATIC User Manual

Parameter sets of signal modules
A.6 Parameters of analog input modules
S7-300 Module data
534 Manual, 06/2017, A5E00105505-AJ
A.6 Parameters of analog input modules
Parameter
The table below lists all parameters you can set for analog input modules.
The comparison illustrates the parameters you can edit:
● in
STEP 7
● using SFC55 "WR_PARM"
Parameters set in
STEP 7 can also be transferred to the module using SFC56 and SFC57
(refer to the
STEP 7 manuals).
Table A- 6 Parameters of analog input modules
Parameters
Data record num-
ber
Programmable, using ...
... SFC55
... PG
Diagnostics: Group diagnostics 0 No Yes
Diagnostics: with wirebreak monitoring
no
yes
Temperature unit
no
yes
Temperature coefficient
no
yes
Smoothing
no
yes
Diagnostic interrupt enable
1
yes
yes
Hardware interrupt when limit exceeded
yes
yes
End of cycle interrupt enable
yes
yes
Interference frequency suppression
yes
yes
Measurement type
yes
yes
Measuring range
yes
yes
High limit
yes
yes
Low limit
yes
yes
Note
To enable diagnostic interrupts in the user program at data record 1, you first need to enable
diagnostics at data record 0 in
STEP 7 .
