Parameter sets of signal modules
A.11 Parameters of analog input module SM 331; AI 6 x TC isolated
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
567
A.11 Parameters of analog input module SM 331; AI 6 x TC isolated
Parameter
The table below shows all parameters you can set at analog input module
SM 331; AI 6 x TC.
The comparison illustrates the parameters you can edit:
● In
STEP 7
● Using SFC55 "WR_PARM"
Parameters set in
STEP 7 can also be transferred to the module using SFC56 and SFC57
(refer to the STEP 7 manuals).
Parameters
Data record
number
Programmable, using ...
... SFC55
... PG
Diagnostics: Channel 0 No Yes
Diagnostics: For wire break
0
No
Yes
Hardware interrupt when limit
exceeded
1 Yes Yes
Diagnostic interrupt enable
1
Yes
Yes
Temperature unit
1
Yes
Yes
Activation of auto-calibration
1
Yes
Yes
Interference frequency suppres-
sion
1 Yes Yes
Measurement type
1
Yes
Yes
Measuring range
1
Yes
Yes
Measured value smoothing
1
Yes
Yes
Response to open thermocouple
1
Yes
Yes
External reference junction
1
Yes
Yes
Temperature coefficient
1
Yes
Yes
High limit
128
Yes
Yes
Low limit
128
Yes
Yes
Note
To enable diagnostic interrupts in the user program at data record 1, you first need to enable
diagnostics at data record 0 in
STEP 7 .
