Parameter sets of signal modules
A.14 Parameters of analog IO modules
S7-300 Module data
580 Manual, 06/2017, A5E00105505-AJ
A.14 Parameters of analog IO modules
Parameter
The table below lists all parameters you can set for analog IO modules.
The comparison illustrates the parameters you can edit:
● in
STEP 7
● using SFC 55 "WR_PARM"
Parameters set in
STEP 7 can also be transferred to the module using SFC 56 and SFC 57
(refer to the
STEP 7 manuals).
Table A- 34 Parameters of analog IO modules
Parameters
Data record number
Programmable, using ...
... SFC 55
... PG
Measuring method 1
yes
yes
Measuring range
yes
yes
Integration time
yes
yes
Output type
yes
yes
Output range
yes
yes
