Digital modules
3.21 Digital output module SM 322; DO 32 x DC 24 V/ 0.5 A; (6ES7322-1BL00-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
135
3.21 Digital output module SM 322; DO 32 x DC 24 V/ 0.5 A;
(6ES7322-1BL00-0AA0)
Order number
6ES7322-1BL00-0AA0
Properties
Properties of SM 322; DO 32 x DC 24 V/0.5 A:
● 32 outputs, electrically isolated in groups of 8
● Output current 0.5 A
● Rated load voltage 24 V DC
● Suitable for solenoid valves, DC contactors and signal lamps
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24
-V power supply to SM 322; DO
32
x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca. 50 µs due to the
circuit str
ucture.
