Siemens SIMATIC User Manual

Analog modules
6.12 Analog output module SM 332; AO 8 x 12 bit; (6ES7332-5HF00-0AB0)
S7-300 Module data
448 Manual, 06/2017, A5E00105505-AJ
6.12.2 Programmable parameters
Introduction
For general information on programming analog modules, refer to the chapter Programming
analog modules (Page 294).
The table below provides an overview of configurable parameters, including defaults:
Table 6- 33 Overview of the parameters of SM 332; AO 8 x 12 Bit
Parameter
Range of values
Default
Parameter
type
Scope
Enable
• Diagnostic interrupt
yes/no no dynamic Module
Diagnostics
• Group diagnostics
Yes/no No static Channel
Output
• Output type
• Output range
disabled
Voltage
Current
See chapter output ranges (Page 447)
V
± 10 V
dynamic Channel
Reaction to CPU STOP ASS
HLV
Outputs zero cur-
rent/voltage
Hold last value
ASS dynamic Channel
Assigning parameters to channels
The parameters can be set separately at each output channel of SM 332; AO 8 x 12 Bit. You
can assign separate parameters to each output channel.
Assign the parameters you set at the SFCs in the user program to the channel groups. Each
output channel of SM 332; AO 8 x 12 Bit is thus assigned to a channel group, i.e. output
channel 0 > channel group 0, for example.
Note
The output may carry invalid inte
rim values if you modify output ranges while SM 332; AO
8
x 12 bit is in RUN.
See also
Diagnostic messages of analog output modules (Page 296)
