Parameter sets of signal modules
A.10 Setting of the analog input module SM 331; AI 8 x 16 Bit (6ES7331-7NF10-0AB0)
S7-300 Module data
560 Manual, 06/2017, A5E00105505-AJ
A.10 Setting of the analog input module SM 331; AI 8 x 16 Bit
(6ES7331-7NF10-0AB0)
Parameter
The table below contains all settings you can set for isolated digital output modules
SM 331; AI 8 ×16 Bit (6ES7331-7NF10-0AB0). This comparison shows which specific
method you can use to configure the various parameters:
● SFC55 "WR_PARM"
●
STEP 7 programming device
Parameters set in
STEP 7 can also be transferred to the module using SFC56 or SFC57.
Table A- 25 Parameters for the electrically isolated analog input module SM 331; AI 8 x 16 Bit
Parameters
Data record no.
Configurable using...
... SFC55
...Programming device
Diagnostics: Group diagnostics 0 no yes
Diagnostics: with wirebreak monitor-
ing
no yes
Hardware interrupt when limit ex-
ceeded
1 yes yes
Diagnostics interrupt enable
yes
yes
End-of-cycle alarm enable
yes
yes
Module operating mode
128
yes
yes
Noise suppression
yes
yes
Measuring method
yes
yes
Measuring range
yes
yes
Smoothing
yes
yes
High limit
yes
yes
Low limit
yes
yes
Note
To enable diagnostic i
nterrupts in the user program at data record 1, you first need to enable
diagnostics at data record 0 in
STEP 7 .
