1.8 Environmental conditions for the operation of SIPLUS S7-300 modules
S7-300 Module data
30 Manual, 06/2017, A5E00105505-AJ
1.8 Environmental conditions for the operation of SIPLUS S7-300
modules
Mechanical environmental conditions
Application class: according to IEC 721-3-3, Class 3M4.
Test of mechanical environmental conditions
The table provides information on the type and scope of the test of mechanical
environmental conditions for SIPLUS S7-300 modules.
Table 1- 3 SIPLUS S7-300 Modules: Test of mechanical environmental conditions
Condition tested
Test Standard
Remarks
Vibration Vibration test acc. to IEC 60068-2-6
(sinusoidal)
Type of oscillation: Frequency sweep at a
rate of change of 1 octave/minute.
5 Hz ≤ f ≤ 9 Hz, constant Amplitude 3.5 mm
9 Hz ≤ f ≤ 150 Hz, constant Acceleration
1 g duration of oscillation:
10 frequency sweeps at each of
three vertically aligned axes
Shock Shock, tested acc. to
IEC 60068-2-27
Type of shock: Half-sine
Severity of shock: 15 g peak value, 11 ms duration
Direction of shock: 3 shocks each in +/– direction in each
of the three vertically aligned axes
