Siemens SIMATIC User Manual

Parameter sets of signal modules
A.12 Parameters of analog output modules
S7-300 Module data
574 Manual, 06/2017, A5E00105505-AJ
A.12 Parameters of analog output modules
Parameters
The table below lists all parameters you can set for analog output modules. The comparison
shows:
● which parameters you can edit in
STEP 7 , and
● which parameters you can change using SFC55 "WR_PARM".
Parameters set in
STEP 7 can also be transferred to the module using SFC56 and SFC57.
Table A- 30 Parameters of analog output modules
Parameters
Data record num-
ber
Programmable, using ...
... SFC55
... PG
Diagnostics: Group diagnostics 0 No Yes
Diagnostic interrupt enable
1
Yes
Yes
Reaction to CPU STOP
Yes
Yes
Output type
Yes
Yes
Output range
Yes
Yes
Substitute value
Yes
Yes
Note
To enable diagnostic interrupts in the user program at data record 1, you first need to enable
diagnostics at data record 0 in
STEP 7 .
