Siemens SIMATIC User Manual

Digital modules
3.39 Programmable digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A (6ES7327-1BH00-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
231
3.39 Programmable digital IO module
SM 327; DI 8/DO 8 x DC 24 V/0.5 A (6ES7327-1BH00-0AB0)
Order number
6ES7327-1BH00-0AB0
Properties
Properties of SM 327; DI 8/DO 8 x DC 24 V/0.5 A:
● 8 digital inputs and 8 individually configurable inputs or outputs, isolated in groups of 16
● Rated input voltage 24 V DC
● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
● Output current 0.5 A
● Rated load voltage 24 V DC
● Outputs capable of driving solenoid valves, DC contactors and indicator lights
● Dynamic change of parameters in RUN (CiR-compatible), separately at each channel.
● Readback of outputs.
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24
-V power supply to
SM 327; DI 8/DO 8
x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca.
50 µs, due to the circuit structure.
