Parameter sets of signal modules
A.5 Settings from the digital output module SM 322; DO 16 x DC 24 V/0.5 A (6ES7322-8BH10-0AB0)
S7-300 Module data
530 Manual, 06/2017, A5E00105505-AJ
A.5 Settings from the digital output module
SM 322; DO 16 x DC 24 V/0.5 A (6ES7322-8BH10-0AB0)
Parameter
The table below contains all parameters you can set for digital output modules.
The comparison illustrates the parameters you can edit:
● in
STEP 7
● using SFC55 "WR_PARM"
● using SFB53 "WRREC" (for GSD, for example).
Parameters set in
STEP 7 can also be transferred to the module using SFC 56 and SFC 57
(refer to the
STEP 7 Online Help).
Table A- 5 Digital output module SM 322; 6ES7322-8HB10-0AB0
Parameter
Data record num-
ber
Programmable, using ...
... SFC55,
SFB53
... PG
Diagnostics: Group diagnostics
1
Yes
Yes
Diagnostics: Load voltage L+ missing
Diagnostics: Discrepancy error
Diagnostics interrupt enable
Behavior at CPU/master STOP
Substitute a value
