5-22 FI SYSTEM
NOTE:
The above form is a standard sample. The form should be modified according to conditions and characteris-
tics of each market.
VISUAL INSPECTION
• Prior to diagnosis using the mode select switch or SDS, perform the following visual inspections. The rea-
son for visual inspection is that mechanical failures (such as oil leakage) cannot be displayed on the
screen with the use of mode select switch or SDS.
* Engine oil level and leakage (2-11)
* Fuel level and leakage (2-10)
* Clogged air cleaner element (2-4)
* Battery condition (9-37)
* Throttle cable play (2-14)
* Vacuum hoses looseness, bend and disconnection
* Broken fuse
* FI light operation (5-16 and 9-29)
* Each warning light operation (9-29)
* Speedometer operation (9-31)
* Exhaust gas leakage and noise (2-24)
* Each coupler disconnection
* Clogged radiator core (7-5)
* Engine coolant level and leakage. (7-6)
MOTORCYCLE/ENVIRONMENTAL CONDITION WHEN PROBLEM OCCURS
Environmental condition
Weather
Fair Cloudy Rain Snow Always Other
Temperature Hot Warm Cool Cold ( °C/ °F) Always
Frequency Always Sometimes ( times/ day, month) Only once
Under certain condition
Road Urban Suburb Highway Mountainous ( Uphill Downhill)
Tarmacadam Gravel Other
Motorcycle condition
Engine condition
Cold Warming up phase Warmed up Always Other at starting
Immediately after start Racing without load Engine speed ( r/min)
Motorcycle con-
dition
During driving: Constant speed Accelerating Decelerating
Right hand corner Left hand corner
At stop Motorcycle speed when problem occurs ( km/h, mile/h)
Other
SAMPLE
To Next Page
