10-22 SERVICING INFORMATION

SPEED SENSOR HARNESS ROUTING

FRONT TURN SIGNAL INSTALLATION

Pass through the speed sensor harness in front of the brake hose

and guide.

5 Clamp

2 Pass through the speed sensor harness in front of the brake hose. 6 Clip

3 Do not catch the speed sensor harness to the caliper boss. 7 Ye l l o w m a r k

4 Touch the stopper 8 Guide

1 No slack

FWD
