Suzuki Boulevard M50 User Manual

EMISSION CONTROL INFORMATION 11-1
11
EMISSION CONTROL INFORMATION
CONTENTS
EMISSION CONTROL SYSTEMS...............................................................11- 2
FUEL INJECTION SYSTEM..................................................................11- 2
EXHAUST EMISSION CONTROL SYSTEM (PAIR SYSTEM).............11- 3
NOISE EMISSION CONTROL SYSTEM...............................................11- 4
EVAPORATIVE EMISSION CONTROL SYSTEM (Only for E-33) ......11- 4
PAIR (AIR SUPPLY) SYSTEM INSPECTION .............................................11- 5
HOSES ..................................................................................................11- 5
PAIR REED VALVE ..............................................................................11- 5
PAIR CONTROL SOLENOID VALVE...................................................11- 6
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING .......................................11- 7
HEATED OXGEN SENSOR (HO2S) INSPECTION (FOR E-02, 19, 24).....11- 8
EVAPORATIVE EMISSION CONTROL SYSTEM INSPECTION
(Only for E-33).............................................................................................11- 9
HOSES (EVAP hose)............................................................................11- 9
EVAP CANISTER..................................................................................11- 9
EVAP CANISTER HOSE ROUTING (Only for E-33)..................................11-10
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
