8-36 CHASSIS
REASSEMBLY AND REMOUNTING
Reassemble and remount the rear wheel in the reverse order of
removal and disassembly. Pay attention to the following points:
WHEEL BEARING
• Apply grease to the bearings before installation.
 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
• Install the wheel bearings with the special tool.
 09941-34513: Bearing installer set

WHEEL DAMPER
• Install the dampers.
NOTE:
If soap water is applied around the damper, it makes the job
easier.
* First, install the right wheel bearing, then install the
left wheel bearings.
* The sealed cover on the bearing must face out.
Left
Right
Spacer
Left
Right
Clearance
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
