CHASSIS 8-69
• In this condition, check the “rim line” B cast on the tire side
walls. The line must be equidistant from the wheel rim all
around. If the distance between the rim line and wheel rim
varies, this indicates that the bead is not properly seated. If
this is the case, deflate the tire completely and unseat the
bead for both sides. Coat the bead with lubricant and fit the
tire again.
• When the bead has been fitted properly, adjust the pressure
to specification.
• As necessary, adjust the tire balance.

 Cold inflation tire pressure
BALANCER WEIGHT INSTALLATION
• When installing the balancer weights to the wheel, set the two
balancer weights A on both sides of wheel rim.

Do not run with a repaired tire at a high speed.
Front Rear
Solo riding
200 kPa
(2.00 kgf/cm², 29 psi)
250 kPa
(2.50 kgf/cm², 36 psi)
Dual riding
200 kPa
(2.00 kgf/cm², 29psi)
250 kPa
(2.50 kgf/cm², 36 psi)
Weight difference between the two balancer weights
must be less than 10 g (0.02 lb).
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
