Suzuki Boulevard M50 User Manual

8-68 CHASSIS
TIRE INSTALLATION
• Apply tire lubricant to the tire bead.
• When installing the tire onto the wheel, observe the following
points.

• When installing the tire, the arrow A on the side wall should
point to the direction of wheel rotation.
• Align the chalk mark put on the tire at the time of removal with
the valve position.
• For installation procedure of tire onto the wheel, follow the
instructions given by the tire changer manufacturer.
• Bounce the tire several times while rotating. This makes the
tire bead expand outward to contact the wheel, thereby facili-
tating air inflation.
• Inflate the tire.

* Do not reuse the valve which has been once removed.
* Never use oil, grease or gasoline on the tire bead in
place of tire lubricant.
* Do not inflate the tire to more than 400 kPa (4.0
kgf/cm², 57 psi). If inflated beyond this limit, the tire
can burst and possibly cause injury. Do not stand
directly over the tire while inflating.
* In the case of preset pressure air inflator, pay special
care for the set pressure adjustment.
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
