Suzuki Boulevard M50 User Manual

PERIODIC MAINTENANCE 2-11
ENGINE OIL AND OIL FILTER
Oil should be changed while the engine is warm. Oil filter
replacement at the above intervals, should be done together
with the engine oil change.
ENGINE OIL REPLACEMENT
• Keep the motorcycle upright.
• Place an oil pan below the engine, and drain oil by removing
the drain plug 1 and filler cap 2.
• Tighten the drain plug 1 to the specified torque, and pour
fresh oil through the oil filler. The engine will hold about 3.0 L
(3.2/2.6 US/Imp qt) of oil. Use of API SF/SG or SH/SJ with
JASO MA.
 Oil drain plug: 21 N·m (2.1 kgf-m, 15.0 lb-ft)
• Start up the engine and allow it to run for several minutes at
idling speed.
• Turn off the engine and wait about three minutes, then check
the oil level through the inspection window A. If the level is
below mark “L”, add oil to “F” level. If the level is above mark
“F”, drain oil to “F” level.
(ENGINE OIL)
Replace initially at 1 000 km (600 miles, 2 months) and
every 6 000 km (4 000 miles, 12 months) thereafter.
(OIL FILTER)
Replace initially at 1 000 km (600 miles, 2 months) and
every 18 000 km (11 000 miles, 36 months) thereafter.
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
