10-50 SERVICING INFORMATION
WATTAGE Unit: W
BRAKE + WHEEL Unit: mm (in)
ITEM
SPECIFICATION
E-03, 28, 33 E-24 Others
Headlight HI 60 ←←
LO 55 ←←
Position/Parking light 5
Brake light/Taillight LED ←←
Turn signal light 21/5 (Front),
21 (Rear)
21 ←
Licence plate light 5 ←←
Speedometer light LED ←←
Engine coolant temp. warning light LED ←←
Turn signal indicator light LED ←←
High beam indicator light LED ←←
Neutral indicator light LED ←←
Oil pressure indicator light LED ←←
FI indicator light LED ←←
ITEM STANDARD LIMIT
Rear brake pedal free travel 20 – 30
(0.8 – 1.2)
----
Rear brake pedal height 75 – 85
(3.0 – 3.3)
----
Brake drum I.D.
Rear ----
180.7
(7.11)
Brake disc thickness
Front
4.8 – 5.2
(0.19 – 0.21)
4.5
(0.18)
Brake disc runout
----
0.30
(0.012)
Master cylinder bore
Front
12.700 – 12.743
(0.5000 – 0.5017)
----
Master cylinder piston diam.
Front
12.657 – 12.684
(0.4983 – 0.4993)
----
Brake caliper cylinder bore
Front
30.230 – 30.306
(1.1901 – 1.1931)
----
Brake caliper piston diam.
Front
30.150 – 30.200
(1.1870 – 1.1889)
----
Wheel rim runout
Axial ----
2.0
(0.08)
Radial ----
2.0
(0.08)
Wheel axle runout
Front ----
0.25
(0.010)
Rear ----
0.25
(0.010)
Wheel rim size Front J16 M/C × MT 3.00 ----
Rear J15 M/C × MT 4.00 ----
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
