Suzuki Boulevard M50 User Manual

SERVICING INFORMATION 10-41
CHASSIS
ITEM
N·m kgf-m lb-ft
Front axle 65 6.5 47.0
Front axle pinch bolt 23 2.3 16.5
Brake disc bolt 23 2.3 16.5
Front fork cap bolt 23 2.3 16.5
Front fork spring stopper nut 35 3.5 25.5
Front fork damper rod bolt 40 4.0 29.0
Front fork upper clamp bolt 23 2.3 16.5
Front fork lower clamp bolt 30 3.0 21.5
Front fork inner rod lock-nut 15 1.5 11.0
Steering stem head nut 90 9.0 65.0
Steering stem nut 45 4.5 32.5
Front master cylinder mounting bolt 10 1.0 7.0
Front brake caliper mounting bolt 39 3.9 28.0
Brake hose union bolt 23 2.3 16.5
Air bleeder valve 7.5 0.75 5.5
Handlebar set bolt 23 2.3 16.5
Handlebar holder nut 45 4.5 32.5
Front footrest bracket mounting bolt 55 5.5 40.0
Frame down tube mounting bolt (M8) 23 2.3 16.5
Frame down tube mounting bolt (M10) 50 5.0 36.0
Rear brake pedal bolt 11 1.1 8.0
Rear swingarm pivot bolt (Left) 100 10.0 72.5
Rear swingarm pivot bolt (Right) 9.5 0.95 7.0
Rear swingarm pivot bolt lock nut 100 10.0 72.5
Rear shock absorber mounting nut
(Upper and Lower)
50 5.0 36.0
Rear cushion lever/rod mounting nut 78 7.8 57.5
Rear axle nut 65 6.5 47.0
Rear torque link nut (front) 35 3.5 25.5
Rear torque link nut (rear) 25 2.5 18.0
Rear brake link pivot bolt 29 2.9 21.0
Rear brake cam lever bolt 10 1.0 7.3
Driven joint stopper bolt 10 1.0 7.0
Frame handle grip mounting bolt (M10) 50 5.0 36.0
Fuel level gauge mounting bolt 10 1.0 7.0
SAMPLE

Suzuki Boulevard M50 Specifications

General

Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Tire	130/90-16M/C 67H, tubeless
Rear Tire	170/80-15M/C 77H, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	700 mm (27.6 in)
Engine Type	4-stroke, liquid-cooled, V-twin
Bore x Stroke	83.0 mm x 74.4 mm
Rear Suspension	coil spring, oil damped
Front Brakes	Single hydraulic disc
Rear Brakes	Drum
Fuel Tank Capacity	15.5 L (4.1 US gal)
Wheelbase	1, 655 mm (65.2 in)
