3-2 ENGINE

ENGINE COMPONENTS REMOVABLE WITH ENGINE IN PLACE

The parts listed below can be removed and reinstalled without removing the engine from the frame. Refer to

the page listed in this section for removal and reinstallation instructions.

ENGINE CENTER

ENGINE LEFT SIDE

ENGINE RIGHT SIDE

PARTS REMOVAL INSTALLATION

Inspection cap

PAIR pipe

Starter motor

Oil filter

3-12

3-11

9-14

3-21

3-85

3-86

9-14

3-72

PARTS REMOVAL INSTALLATION

Neutral switch

Generator

Water pump

Secondary driven bevel gear

3-22

3-23

3-24

3-72

3-71

3-69

3-68

PARTS REMOVAL INSTALLATION

Clutch

Oil pump

Gearshift

Primary drive gear

Driveshaft bolt/Secondary driven gearshaft nut

3-18

3-20

3-21

3-76

3-74

3-73

3-69
