Suzuki DL1000 Service Manual

3-70 ENGINE
• Remove the oil seal.
#
• Remove the oil seal with the special tool.
" 09913-50121: Oil seal remover
#
• Remove the bearing retainers.
• Remove the bearings with the special tool.
" 09921-20240: Bearing remover set
NOTE:
If there is no abnormal noise, the bearing removal is not neces-
sary.
• Install the bearings with the special tool.
" 09913-70210: Bearing installer set
NOTE:
The sealed side of the driveshaft bearing must face outside.
The removed oil seal must be replaced with a new one.
The removed oil seal must be replaced with a new one.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
