Suzuki DL1000 Service Manual

8-46 SERVICING INFORMATION
WATTAGE
Unit: W
BRAKE + WHEEL
Unit: mm (in)
ITEM
SPECIFICATION
E-03, 24, 28, 33 The others
Headlight HI
60 × 2 ←
LO
55 × 2 ←
Position light
5 × 2
Brake light/Taillight
21/5 × 2 ←
Turn signal light
10 × 4 ←
Speedometer
Tachometer light
LED ←
Turn signal indicator light
LED ←
High beam indicator light
LED ←
Neutral indicator light
LED ←
Over drive indicator light LED ←
Coolant temperature warning
light
LED ←
Oil pressure warning light LED ←
Fuel injection warning light LED ←
License light 5 ←
ITEM STANDARD LIMIT
Rear brake pedal height 20 – 30
(0.8 – 1.2)
—
Brake disc thickness
Front
5.0 ± 0.2
(0.197 ± 0.008)
4.5
(0.18)
Rear
5.0 ± 0.2
(0.197 ± 0.008)
4.5
(0.18)
Brake disc runout
(Front & Rear)
—
0.30
(0.012)
Master cylinder bore
Front
15.870 – 15.913
(0.6248 – 0.6265)
—
Rear
14.000 – 14.043
(0.5512 – 0.5529)
—
Master cylinder piston diam.
Front
15.827 – 15.854
(0.6231 – 0.6242)
—
Rear
13.957 – 13.984
(0.5495 – 0.5506)
—
Brake caliper cylinder bore
Front
30.230 – 30.306
(1.1902 – 1.1931)
—
Rear
38.180 – 38.230
(1.5031 – 1.5051)
—
Brake caliper piston diam.
Front
30.150 – 30.200
(1.1870 – 1.1890)
—
Rear
38.098 – 38.148
(1.4999 – 1.5019)
—
Wheel rim runout
(Front & Rear)
Axial —
2.0
(0.08)
Radial —
2.0
(0.08)
