Suzuki DL1000 Service Manual

ENGINE 3-91
• Install the bushings
A into the crankcase and generator
cover.
NOTE:
Apply molybdenum oil solution to the inside of the bushings.
) MOLYBDENUM OIL
• Fit the washers onto the starter torque limiter.
• Install the starter torque limiter.
• Install the dowel pin and gasket.
#
• Install the generator cover.
NOTE:
Install the bracket
B.
Use the new gasket to prevent oil leakage.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
