Suzuki DL1000 Service Manual

CHASSIS 6-5
FRAME COVERS
• Remove the seat. (!6-4)
• Remove the carrier. (!6-4)
• Remove the fuel tank cover. (!6-4)
• Remove the screw
1 and clip 2.
• Remove the frame cover by pulling on the hooked part.
✩: hooked part
REAR FENDER
• Remove the seat. (!6-4)
• Remove the carrier. (!6-4)
• Remove the bolts.
• Disconnect the brake light/taillight lead wire coupler.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
