Suzuki DL1000 Service Manual

CHASSIS 6-17
• Remove the dust seal.
• Remove the oil seal stopper ring.
• Pull the inner tube out of the outer tube.
NOTE:
Be careful not to damage the inner tube.
"
• Remove the following parts.
A Oil seal
B Oil seal retainer
C Guide metal
D Slide metal
The slide metals, oil seal and dust seal must be
replaced with the new ones when reassembling the
front fork.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
