CHASSIS 6-41
• Install the rear sprocket mounting drum to the rear wheel.
• Install the collar.
REAR AXLE
• Remount the rear wheel and rear axle, install the washer and
rear axle nut.
• Tighten the rear axle nut
1 to the specified torque.
• Adjust the chain slack after rear wheel installation. (!2-19)
& Rear axle nut: 100 N·m (10.0 kgf-m, 72.5 lb-ft)
• Install the new cotter pin. (For E-03, 28, 33)

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
