Suzuki DL1000 Service Manual

7-24 ELECTRICAL SYSTEM
ODOMETER
The odometer indicates “-----” when the odometer is faulty.
Replace the combination meter unit with a new one.
TRIP METER
The trip meter indicates “-----” when the trip meter is faulty.
In case the odometer works normaly, perform the trip meter
reset. If the trip meter isn’t restored after above reset, replace
the combination meter unit with a new one.
TRIP METER RESET PROCEDURE
1. Turn the ignition “ON”.
2. Select the trip meter by pushing the mode switch
A.
3. Push the set switch
B for 2 seconds.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
