Suzuki DL1000 Service Manual

3-38 ENGINE
CYLINDER HEAD
• Remove the tappets and shims
1 by fingers or magnetic
hand.
• Using special tools, compress the valve spring and remove
the two cotter halves
2 from the valve stem.
" 09916-14510: Valve lifter
09916-14910: Valve lifter attachment
09916-84511: Tweezers
• Remove the valve spring retainer
3 and valve spring 4.
• Pull out the valve from the other side.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
