ELECTRICAL SYSTEM 6-23
SPEEDOMETER
REMOVAL AND DISASSEMBLY
Remove the speedometer assembly. ( 5-23)
Disassemble the speedometer, as shown.
INSPECTION
Check the continuity between the lead wires using the multi cir-
cuit tester. If there is no continuity, replace the respective parts.
09900-25008: Multi circuit tester set
Tester knob indication: Continuity test ( )
