Suzuki UF50 - Engine Components Removable with the Engine in Place

3-2 ENGINE
ENGINE COMPONENTS REMOVABLE WITH THE ENGINE IN PLACE
The parts listed below can be removed and reinstalled without removing the engine from the frame. Refer to
the page listed in each section for removal reinstallation instructions.
ENGINE LEFT SIDE
PARTS REMOVAL INSTALLATION
Air cleaner 3-6 –
Kick starter lever 3-9 3-39
Clutch cover 3-9 3-39
Kick starter 3-9 3-38
Fixed drive face 3-9 –
Movable drive face 3-9 3-38
Clutch housing 3-9 3-38
Clutch shoe assembly 3-9 –
Drive belt 3-9 3-38
Starter driven gear 3-9 3-37
Starter pinion gear 3-10 3-37
ENGINE RIGHT SIDE
PARTS REMOVAL INSTALLATION
Exhaust pipe/muffler assembly 3-6 3-40
Cooling fan 3-7 –
Starter motor 3-8 –
Generator rotor 3-10 3-37
Stator coil 3-10 3-36
Pickup coil 3-10 3-36
Gearbox cover 3-11 3-35
Final driven gear 3-11 3-34
ENGINE CENTER
PARTS REMOVAL INSTALLATION
Oil pump 3-6 –
Oil pump gear 3-7 3-40
Intake pipe 3-7 3-40
Reed valve 3-7 –
Cylinder head 3-8 3-40
Cylinder 3-8 3-40
Piston 3-8 3-39
