CHASSIS 5-7
Remove the brake disc.
INSPECTION AND DISASSEMBLY
SPEEDOMETER GEARBOX DUST SEAL
Inspect the speedometer gearbox dust seal for damage. If any
damage is found, replace the speedometer gearbox with a new
one.
WHEEL BEARINGS
Inspect the play of the wheel bearings by hand while they are in
the wheel. Rotate the inner race by hand to inspect for abnormal
noise and smooth rotation. If any abnormal noise occurs, or rough
movement is noted, replace the wheel bearings with new ones.
Remove the wheel bearings as follows:
Insert the bearing remover attachment 1 into the wheel bear-
ing.
Insert the wedge bar 2 from the opposite side and lock it into
the slit of the bearing remover attachment.
Drive out the wheel bearing by striking the wedge bar.
09941-50111: Bearing remover
Replace the removed bearings with new ones.
