SERVICING INFORMATION 7-19
TIGHTENING TORQUE
ENGINE
ITEM N·m kgf-m
Cylinder head nut 10 1.0
Spark plug 28 2.8
Exhaust pipe mounting nut and bolt 10 1.0
Engine mounting bracket nut 65 6.5
Engine mounting nut 60 6.0
Clutch housing nut 50 5.0
Kick starter nut 50 5.0
Generator rotor nut 40 4.0
Clutch shoe nut 50 5.0
Kick starter lever bolt 10 1.0
Final gear oil drain bolt 5.5 0.55
Final gear oil level bolt 12 1.2
Oil pump mounting screw 4 0.4
CHASSIS
ITEM N·m kgf-m
Steering stem locknut 30 3.0
Handlebar clamp nut 50 5.0
Handlebar set bolt 25 2.5
Front brake caliper mounting bolt 26 2.6
Front brake hose union bolt 23 2.3
Front brake caliper air bleeder valve 7.5 0.75
Front brake caliper housing bolt 32 3.2
Front brake disc bolt 23 2.3
Front brake master cylinder bolt 10 1.0
Front axle nut 42 4.2
Rear axle nut 120 12.0
Rear shock absorber bolt (upper) 29 2.9
Rear shock absorber nut (lower) 35 3.5
Rear brake cam lever nut 10 1.0
