PERIODIC MAINTENANCE 2-7
CARBURETOR
Inspect Initially at 1 000 km (2 months) and every
3 000 km (6 months) thereafter.
ENGINE IDLE SPEED
Adjust the throttle cable play.
Remove the left side leg shield. ( 5-3)
Warm up the engine.
NOTE:
Make this adjustment when the engine is hot.
Connect the multi circuit tester to the high-tension cord.
Start the engine, and then turn the throttle stop screw 1 to
set the engine idle speed as shown below.
Engine idle speed: 1 900 ± 200 r/min
09900-25008: Multi circuit tester set
THROTTLE CABLE PLAY
Throttle cable play A should be 2 – 4 mm as measured at the
throttle grip when turning the throttle grip lightly. If the throttle
cable play A is incorrect, adjust it as follows:
Loosen the locknut 1 and turn the adjuster 2 in or out until
the specified play is obtained.
Tighten the locknut 1 while holding the adjuster 2.
Throttle cable play A: 2 – 4 mm
After the adjustment is completed, check that handle-
bar movement does not raise the engine idle speed
and that the throttle grip returns smoothly and auto-
matically.
FUEL LINE
Inspect initially at 1 000 km (2 months) and every
3 000 km (6 months) thereafter.
Replace every four years.
