CHASSIS 5-5
Remove the upper fuel tank cover 1.
After removing the upper fuel tank cover, reinstall the fuel tank
cap.
Remove the passenger grab handle 2.
Remove the frame cover mounting screw.
Disconnect the seat lock cable 3, brake light/taillight lead
wires 4, and remove the frame cover 5.
REMOUNTING
Remount the leg shield, seat, and frame cover in the reverse
order of removal.
