4-4
FUEL AND LUBRICA
TION SYSTEM
Remov
e the fuel tank cap
1
and fuel tank
2
.
NO
TE:
After removing the fuel tank, reinstall the fuel tank cap
.
Disconnect the oil hose
3
, oil le
vel indicator s
witch coupler
4
,
and remov
e the oil tank
5
.
REMOUNTING
Remount the fuel tank and oil tank in the rev
erse order of re-
mov
al.
1
2
5
3
4
72
74
