Suzuki UF50 - Kick Starter

ENGINE 3-25
KICK STARTER
1 Spacer
2 Kick starter shaft
3 Kick starter spring
4 Clutch cover
5 Dowel pin
6 Gasket
7 Gasket
8 Kick starter lever
9 Kick starter drive gear
DISASSEMBLY
Remove the kick starter driven gear 1, kick starter shaft
spring 2, and kick starter shaft 3.
REASSEMBLY
Apply SUZUKI SUPER GREASE “A” onto the inside of the
kick starter shaft spacer.
99000-25010: SUZUKI SUPER GREASE “A”
2
3
1
