FUEL AND LUBRICATION SYSTEM 4-3
FUEL TANK AND OIL TANK
REMOVAL
Gasoline is highly flammable and explosive.
Keep heat, sparks, and flames away from gasoline.
Remove the frame cover. ( 5-4 and 5-5)
Disconnect the turn signal light lead wires 1 and license plate
light coupler 2.
Disconnect the fuel level indicator switch coupler.
Disconnect the air vent hose 3 and fuel hose 4.
Remove the lower fuel tank cover mounting bolts.
4
To Next Page
