SERVICING INFORMATION 7-23
ELECTRICAL
Unit: mm
ITEM SPECIFICATION NOTE
Spark plug
Type
NGK: BPR7HS
DENSO: W22FPR
Gap 0.6 – 0.7
Spark performance Over 8 at 1 atm.
Ignition coil resistance
Primary 0.2 – 1.5 Ω W/Bl – B/W
Generator coil resistance
Lighting 0.3 – 1.5 Ω Y/W – Ground
Pickup
120 – 250 Ω W – Br
Regulated voltage 13.5 – 15.0 V at 5 000 r/min
Generator maximum output 125 W at 5 000 r/min
Starter relay resistance 50 – 90 Ω
Battery
Type designation CB4L-B, FB4L-B
Capacity
12 V 14.4 kC (4 Ah)/10 HR
Standard electrolyte
specific gravity
1.280 at 20°C
Fuse size 10 A
WATTAGE
Unit: W
ITEM SPECIFICATION
Headlight HI 35
LO 35
Brake light/Taillight 21/5
Turn signal light 10
Speedometer light 2
Fuel level indicator light 2
Turn signal indicator light 2
Oil level indicator light 2
High beam indicator light 1.2
License plate light 5
Secondary
10 – 20 kΩ Plug cap-B/W
Ignition coil primary peak voltage
More than 150 V
+: Ground
-: W/Bl
Charging 0.5 – 2.0 Ω W/R – Ground
Pickup coil peak voltage More than 5.0 V +: W -: Br
